Shop Kyoritsu KEW 4106 Earth Resistance Tester at best price from uazon

Kyoritsu KEW 4106 Earth Resistance Tester

Back to catalog
4,417.00 AED
In stock
Product Details
Brand: kyoritsu
Earth Resistance Range: 2Ω to 200kΩ
Overload Protection: between E-S(P) and between E-H(C) terminals AC280V / 10 sec.
Safety Standard: IEC 61010-1 CAT III 300V, CAT IV 150V Pollution degree 2
Dimension: 167(L) × 185(W) × 89(D) mm

Kyoritsu 4106 Earth Tester

The Kyoritsu KEW 4106 Earth Resistance Tester is another specialized electrical testing instrument used for measuring the resistance of earth (ground) connections in electrical installations. It is designed to help ensure the safety and proper functioning of grounding systems by providing accurate earth resistance measurements.

We offer various models kyoritsu earth testers at competitive price in UAZON.

KEW 4106 Key Features

  • High test current up to 80mA yielding resolution of 0.001Ω on 2Ω range.
  • Advanced Filtering method (based on FFT Fast Fourier Transform) reduces noise interference for obtaining stable measurements.
  • Automatic and Manual selection of the Test Current Frequency in four bands (94/105/111/128Hz). In Automatic mode, KEW 4106 will select the most suitable Frequency.
  • Several sub-results can be shown on the display: Resistance of the Auxiliary Earth Spikes, Frequency of Test Current, Voltage and Frequency of Interference (noise), Residual Resistance Rk, etc.
  • Warning for excessive noise and high Auxiliary Earth Spikes resistance.
  • Large Graphic Display with backlight for readings in poorly illuminated areas.
  • Up to 800 measurement results can be saved in the memory and recalled on the display.
  • The stored results can be transferred to a PC using the "KEW Report" software and a USB adaptor (Model 8212-USB) which are included.
  • Robust design with IP54 protection

Kew 4106 Specifications

Function Range Resolution Measuring range Accuracy
Earth resistance 2Ω 0.001Ω 0.03 - 2.099Ω ±2%rdg±0.03Ω
Re 20Ω 0.01Ω 0.03 - 20.99Ω ±2%rdg±5dgt (*1)
(Rg at 200Ω 0.1Ω 0.3 - 209.9Ω
ρ measurement) 2000Ω 1Ω 3 - 2099Ω
20kΩ 10Ω 0.03k - 20.99kΩ
200kΩ 100Ω 0.3k - 209.9kΩ
Auxiliary earth resistance 8% of Re+Rh+Rs
Rh, Rs
Earth resistivity 2Ω 0.1Ωmm - 1Ωm 0.2 - 395.6Ωm ρ=2×π×a×Rg (*2)
ρ 20Ω Autoranging 0.2 - 3956Ωm
200Ω 20 - 39.56kΩm
2000Ω 0.2 - 395.6kΩm
20kΩ 2.0 - 1999kΩm
200kΩ
Series interference voltage 50V 0.1V 0 - 50.9Vrms ±2%rdg±2dgt (50/60Hz)
Ust (A.C only) (*3) ±3%rdg±2dgt (40 - 500Hz)
Frequency Autoranging 0.1Hz 40Hz - 500Hz ±1%rdg±2dgt
Fst 1Hz
Measuring method Earth resistance: Fall-of-potential method
(currents and voltages measured via the Probes)
Measurement method of Earth Resistivity (ρ): Wenner 4-pole method
Series interference voltage (earth voltage)
RMS Rectifier (between the E-S Terminals)
Memory capacity 800 data
Communication Interface Model 8212-USB Optical Adaptor
LCD Dot-matrix 192×64 monochrome
Over-range Indication "OL"
Overload Protection between E-S(P) and between E-H(C) terminals AC280V / 10 sec.
Applicable standards IEC 61010-1 CAT III 300V, CAT IV 150V Pollution degree 2
IEC 61010-031, IEC 61557-1, 5, IEC 61326-1 (EMC), IEC 60529 (IP54)
Power source DC12V : sizeAA manganese dry battery (R6) × 8
(Auto power off: approx. 5 minutes)
Dimensions 167(L) × 185(W) × 89(D) mm
Weight approx. 900g (including batteries)
